CHAPTER 8: TROUBLESHOOTING
8.10 TROUBLESHOOTING - ERROR 01AC
FIGURE A
ERROR CODE 01AC
1) SYMPTOM:
01AC - Resistance over current
2) SOLUTION:
1) Check if the resistance is short circuited by measuring amperage through the generator cable (Figure A).
- If the resistance value is under 10 ohms, replace the generator.
- If the resistance value is over 10 ohms, replace the LCB.
