Matrox Monarch Series - Page 2

Matrox is a registered trademark and Monarch is a trademark of Matrox Electronic Systems Ltd.
Y11349-601-0300 Copyright © 2018 by Matrox Electronic Systems Ltd. All rights reserved. Printed in Canada.
Monarch HD, HDX, and LCS mounting
M
M / M
AUX
A
M / E
M / M
AUX
19.00" / 48.26 cm
0.85" / 2.16 cm
17.30" / 43.94 cm
7.75" /
19.68 cm
or
5.64” /
14.33 cm
(older versions)
A = AVIO
M = MAEVEX 5150
M / M = MAEVEX / MONARCH5150 HD
M / E = MAEVEX 6150 / EXTIO N3x08
AUX = MONARCH HDX / LCS
M
M
M
M
M
M
P/N: F2920-03 REV A
M / M
M / M
M / M
AUX AUX
A
A
M / E M / E
A
A
MONARCH HD
Use the outer “M / M” holes
MONARCH HDX and LCS
Use the “AUX” holes
NOTE: Secure the angled
brackets to Monarch before
attaching to the mounting shelf.
Use lower screw holes for
Monarch HDX and LCS, upper
screw holes for Monarch HD.
MONARCH HD
MONARCH LCS and HDX
