DISCRIPTION OF COMPONENTS AND PARTS
DIAGRAM OF INSTRUMENT PANEL
Economical Gear, corresponding to number ”1”
Cruising Gear, corresponding to the number “2”
Sport Gear, corresponding to the number “3”
Winker indicator, flashing in synchronization
with the left and right winker.
High beam indicator, indicating highbeam on.
Parking indicator, indicating the parking state.
Charging
1. Speed display
display current speed.
2. Ambient temperature
Display current ambient temperature
3. driving time
Display Single driving time
4. ODO/TRIP
Total ODO Distance/ TRIP distance
5. Power display bar
Display current battery level
6. Gear display
Display current gear
7. Failure warning display
current failure (motor, controller,
brake, accelerator)
8. Left indicator light
Left indicator for turning
9. READY light
Ready for driving
10. Under-voltage of Battery
Under-voltage warning Display of
current battery
11. Right indicator light
Left indicator for turning
12. Parking gear
Parking de scooter
13. Recover display
Recover current failure
The charge indicating lamp lights up when less
than 10%electricity remains.
The start indicator lights up when the motor
can be started.
normal
sport
eco
READY
