Matweld 05000 - Page 11

11
MATWELD, INC. PHONE:(270) 444-0085 FAX:(270) 443-6180
Matweld reserves the right to change parts, features, or specifications without notice.
10/09
ITEM NO. PART NO. DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
HAND PUMP BODY
PIVOT ARM
CONNECTING LINK
PIVOT BRACKET
-010 O-RING
RESERVOIR TANK
-236 O-RING
CHECK VALVE
-212 O-RING @ PUMP BODY
BACK UP WASHER
PISTON
SPRING
5/16 PRECISION STEEL BALL
CHECK PLUG
CYLINDER PLUG
RESERVOIR BAFFLE
BACK UP WASHER
0214 O-RING @ PISTON
CAP PLATE
RELIEF VALVE CARTRIDGE ST
OIL SEAL
CHECK VALVE
-2 O-RING PLUG
-6 O-RING PLUG
1/4-20 x 1/2 HEX HEAD BOLT
1/4-20 x 3/4 HEX HEAD BOLT
1/4-20 x 5 1/2 HEX HEAD BOLT
3/8-16 x 1 HEX HEAD BOLT
1/4 NPT NYLOCK NUT
5/16-18 NYLOCK NUT
1/4 SAE FLAT WASHER
3/8 SAE FLAT WASHER
3/8 LOCK WASHER
DIA. 3/8 x 1 1/4 SHOULDER BOLT
00925A
00914
00915
00917
00919
00922
00923
00924
00926
00927
00928
00929
00930
00931
00932
00933
00934
00935
00936
00938
00939
00140
231P-02
231P-06
A1000
A1001
A1017
A1042
A1473
A2048
A2190
A2192
A3811
A6940
QTY.
1
1
2
1
2
1
1
1
1
1
1
1
1
1
1
1
3
2
1
1
1
1
3
1
1
4
2
4
1
3
7
8
4
3
05000 HAND PUMP WELD SHEAR
1517 18 14
13
17
18 17 12 9 21
10
11
THIS VIEW SHOWS THE LOCATION OF THE
COMPONENTS THAT GO INSIDE THE 00925A
MAKE SURE THE MARKING
"FLU ID SIDE" ARE TO THE
OUTSIDE OF THE PUMP
WHEN INSTALLING SEAL
