7
2. Terminal Interface
1
HDMI OUT*
Connect to the devices with HDMI input function
2
SPDIF
Carry multichannel sound via optical signals.
3
HDMI1(ARC)&
HDMI2
High-definition multimedia interface signal input,
connect to devices with HDMI output interface
(personal computer with HDMI output, set-top box,
or another video device)
4
Display Port
Connected to devices with Display Port output
function
5
RS232
Serial interface, used for mutual transfer of data
between devices
6
VGA
External computer image input
7
PC LINE IN
External computer audio input
8
USB3.0
USB 3.0,connect USB devices such as U disk, USB
keyboard , USB drives, etc.
9
USB1&USB2
USB 2.0,connect USB devices such as U disk, USB
keyboard , USB drives, etc.
10
AUDIO OUT
Audio output to the external speaker
11
LAN
Connect RJ45 terminals
12
AC SWITCH
To open or shut down AC power supply.“I” means
power on,“O” means power off
13
AC IN
AC power input, connect AC power supply
Note :【*indicates partial terminals are optional.
