9
l
Power button : short press to turn on; In the
start up state : short press to dormancy, long
press 2 seconds to soft-off, long press 10
seconds to forced shutdown.
m
AUX OUT1(3.5) : Audio output to the external
speaker.
n
AUX OUT2(6.5) : Audio output to the external
speaker.
o CANNON : Audio output to the external
speaker.
p HDMI OUT : Connect to the devices with HDMI
input function.
q AC IN : AC power input, connect AC power
supply.
