model no. 054-2433-0 | contact us 1-888-670-6682
No. Part No. Description No. Part No. Description
1 3131140000 Top Cover 23 4860818000
Internal Wire
Assembly
2 4900277000 Speed Adjustor 24 2822039000
Internal Wire
ASSY
3 4810003000
Power Cord &
Plug
25 2740118000 Stator
4 3131141000 Middle Housing 26 4870758000 Rocker Switch
5 4930008000 Sleeve 27 4860004000 Inner Wire
6 3121050000 Cord Guard 28 3122798000
Cord
Anchorage
7 3120537000 Brush Cover 29 5610106000 Tapping Screw
8 4960019000
Carbon Brush
Assy
30 5620017000
Hexagon
Socket Screw
9 2800005000
Brush Holder
Assy
31 5610059000
Thread
Forming Screw
10 2823114000 Rotor Set 32 5610076000 Tapping Screw
11 3121518000
Transparent
Cap
33 5620069000 Screw
12 5610017000 Tapping Screw 34 2823021000
LED Holder
ASSY
13 2822038000
Internal Wire
ASSY
35 5620041000 Screw
14 4620466000 Screw 36 3320460000
Adjusting
Knob
15 5610220000
Thread
Forming Screw
37 3123281000 Indicator
16 3125687000 Fan Baffle 38 3550854000 Shaft
17 5630179000 Nut 39 3703872000 Plate
18 5610050000 Tapping Screw 40 2823122000 Lever Assy
19 2823022000
Spindle Lock
ASSY
41 5630015000
Prevailing
Torque
Hexagon Nut
20 5700056000 Bearing 42 2827570000
Mounting
Assembly
21 3422740000 Housing 43 2822272000
Adjusting
ASSY
22 2823121000
Collet
Assembly
44 3322854000 Handle
PARTS LIST
