Maxitrol GV60 - Gas Pressure Test Ports

20
Inlet or System Pressure
Manifold or
Burner Pressure
WARNING: The pressure test ports use a captured screw. It will not fall out but it must be
retightened after checking both inlet and manifold pressure.
IMPORTANT! Check pressure test ports for leaks after test is complete.
Control Valve Components
Gas Pressure Test Ports
