11
CONNECTION DIAGRAM
SPECIFICATIONS
ENGLISH
TBO9
Input Impedance
Output Impedance
Maximum Gain
Equivalent Input Noise
Control
Internal Circuit Voltage
Power Consumption
Dimensions
Weight
Power Supply
Accessory
* 0dB=0.775Vrms
* All specifications are subject to change for improvement without notice or obligation.
* The subminiature tube used for this model is not a socket type.
It cannot be replaced with other tube.
: 500k ohms
: 10k ohms or less
: 52dB (1.6 kHz)
: -110dB or less (IHF-A)
: BOOST, DRIVE, TONE, LEVEL
: 30VDC (DC to DC converter)
: 270mA/9VDC
: 74(W) x124(D) x 54(H) mm
: 560g (excluding AC adaptor)
: AC adaptor AC2009 (Not operated with battery.)
: AC adaptor AC2009
TBO9
AC2009
