13
tone and function.
●Dual outputs allow you to play with two amplifiers for stereo chorus effects.
●High-performance Noise Reduction (which consists of RMS level sensor and
high-definition VCA) provides high dynamic range with low noise. Clean cho-
rus without distortion is available with high-headroom.
●Connectable to effect loop of guitar amp. (+4dB/-20dB)
●TBS (True Bypass Switching) with 4PDT mechanical switch. No tone
changes when switching bypass and effect.
●Easy-access, no tools battery compartment.
④WIDTH
Controls modulation depth. Turn it
clockwise for deeper modulation.
⑤PURE
Switch for chorus tone. When PURE
switch is ON, delayed signal and the
dry signal are mixed at even levels,
creating pure chorus based on the
chorus theory. When PURE Switch
is OFF, level of Delayed signal only
is increased by 4dB and then mixed
with dry signal, creating tremolo-like
chorus.
⑥BRIGHT
When BRIGHT switch is ON, harsh
low-frequency range of chorus sound
is decreased, creating a brighter
sound. When switch is off, standard
flat chorus sound is available.
⑦FOOTSWITCH
Switch for effect/bypass. Stepping on
this switch alternately turns effects
on and off.
* Effect turns on when you depress
the switch and effect turns off when
you depress and release the switch.
⑧LED INDICATOR
This indicates the effect/bypass sta-
tus and battery condition. At the bat-
tery operation, it lights when plug is
inserted to input jack and effect is
on. At the external power supply (AC
adaptor) operation, it lights when ef-
fect is on. No LED light indicates the
battery is low or not installed. In this
case replace the battery.
⑨DC INPUT
Jack for connection of external pow-
er supply to effect. Be sure to use
the correct Maxon AC adaptor.
Turn down amplifier’s volume
to the minimum before con-
necting AC adaptor to the product in
order not to damage other connect-
ed equipment.
ENGLISH
PAC9
