17
●High-performance NR (which consists of RMS level sensor and high-definition VCA) provides
high dynamic range with low noise. Clean flanging effect without distortion is available with
high-headroom.
●Connectable to effect loop of guitar amp. (+4dB/-20dB)
●TBS (True Bypass Switching) with 4PDT mechanical switch. No tone changes when switching
bypass and effect.
●Easy-access, no tools battery compartment.
●AC adaptor AC2009 can be used worldwide from 100VAC to 240VAC by auto voltage sens-
ing. Main countries’ safety standard approved. Useful for worldwide touring musicians.
function is different. Latching type alternately turns
ON and OFF when switch is depressed. For mo-
mentary type, jet sound is ON when you depress
the switch and jet sound is OFF when you release
the switch. Normally closed type of momentary
switch should be used.
④RANGE
Controls tone range of jet sound. Turn it clockwise
for wider range of tone. VCF of jet sound is band-
pass type. Center frequency at no guitar input sig-
nals is approx. 70Hz. As guitar input signals in-
crease, it changes to approx. 2kHz at maximum.
Jet effect is adjusted by the following three con-
trols; RANGE, SENSITIVITY and JET. These con-
trols are mutually related. When either one of these
controls is turned fully counterclockwise, no jet
sound is available. If there is no guitar signal, no jet
sound is outputted.
⑤JET
Controls volume of jet sound generator. Turn it
clockwise for larger volume. No jet sound is avail-
able in the fully counterclockwise position. VJR9
can be used as a flanger in the fully clockwise po-
sition.
⑥SENSITIVITY
Controls sensitivity of jet sound. Set it to pickup
output characteristic of your guitar and/or perform-
ance. Turn it clockwise for high sensitivity.
⑦SPEED
Controls modulation speed. Turn this knob clock-
wise for faster modulation.
⑧WIDTH
Controls modulation depth. Turn this knob clock-
wise for deeper modulation. No modulation is
available in the fully clockwise position.
⑨FOOTSWITCH
Switch for effect/bypass. Stepping on this switch
alternately turns effects on and off.
* Effect turns on when you depress the switch
and effect turns off when you depress and re-
lease the switch.
⑩LED INDICATOR
This indicates the effect/bypass status and bat-
tery condition. At the battery operation, it lights
when plug is inserted to input jack and effect is
on. At the external power supply (AC adaptor) op-
eration, it lights when effect is on. No LED light
indicates the battery is low or not installed. In this
case replace the battery with a new one.
⑪DC INPUT
Jack for connection of external power supply to
effect. Be sure to use the correct Maxon AD
adaptor.
* Turn down amplifier’s volume to the mini-
mum before connecting AC adaptor to the
product in order not to damage other connected
equipment.
ENGLISH
VJR9
