Input Impedance
Output Impedance
Maximum Gain
Equivalent Input Noise
Control
Switch
Indicator
Internal Circuit Voltage
Power Consumption
Dimensions
Weight
Power Supply
Battery Life
Option
* 0dB = 0.775Vrms
* All specifications are subject to change for improvement without notice or obligation.
: 500k ohms
: 10k ohms or less
: 52.5dB (4kHz)
: -60dB or less (IHF-A)
: GAIN, SCOOP, LEVEL, EDGE
: Bypass/Effect, Voltage Switch (9V/18V)
: Bypass/Effect LED, 9V LED, 18V LED
: 9VDC / 18VDC (DC to DC Converter)
: 12mA/9VDC, 42mA/18VDC
: 74 (W) ×124 (D) × 54 (H) mm
: 600g (including battery)
: 6F22 / 6LR6 9V battery × 1 or Maxon AC adaptor
: 9VDC manganese battery 27 hours 25℃(Panasonic 6F22NB)
: 9VDC alkaline battery 50 hours 25℃(Panasonic 6LR61G)
:
18VDC manganese battery 1.3 hours 25℃(Panasonic 6F22NB)
: 18VDC alkaline battery 6 hours 25℃(Panasonic 6LR61G)
: AC adaptor (Refer to page 29.)
27
CONNECTION DIAGRAM
SPECIFICATIONS
ENGLISH
SM9Pro+
