Maxton UC1A - EXTERIOR DIMENSIONS UC4, UC4 M, UC4 MR B44

1728 Orbit Way - Minden, Nevada 89423 P: 775-782-1700 F: 775-782-1701 info@maxtonvalve.com www.maxtonvalve.com

36
\\SERVER\CATALOG2019\2019CatalogRev2

DL
D
B
A
BPS
R
CENTER LINE OF PUMP
Top View
ADJUSTER MAX LENGTH
UC4M
SHOWN
PUMP
CENTER LINE OF PUMP
93/16”
(233mm)
65/8”
(168mm)
51/16”
(129mm)
11/2”(38mm)
101/2”
(267mm)
Front View
313/16”
(97mm)
41/4”
(108mm)
23/16”
(55mm)
313/16”
(97mm)
87/16”
(214mm)
45/8”
(117mm)
EXTERIOR DIMENSIONS UC4, UC4M, UC4MR B44
