Maxton UC1A - SOLENOID, SOLENOID SEAT & BALL CAGE KITS

1728 Orbit Way - Minden, Nevada 89423 P: 775-782-1700 F: 775-782-1701 info@maxtonvalve.com www.maxtonvalve.com

86
\\SERVER\CATALOG2019\2019CatalogRev2

Disconnect power and land car on the buffers (zero system pressure) before installation. Do not save and reuse parts.
292920 SOLENOID KIT FOR UC4 / UC4M / UC4MR 
Quantity Part No.
Description
Quantity Part No.
Description
1 29298A-2 Solenoid Seat Kit 4 282920 Solenoid Tube Assembly
1 292950 Ball Cage Kit
4 238500
Seal Ring (Solenoid Tube)

29292A SOLENOID KIT FOR UC1A / UC1 / UC2A / UC2
Quantity Part No.
Description Quantity Part No. Description
1 29298A-2 Solenoid Seat Kit 1 28292A Solenoid Tube Assembly
1 292950 Ball Cage Kit 3 282920 Solenoid Tube Assembly
4 238500 Seal Ring (Solenoid Tube)   

29298A-2 SOLENOID SEAT KIT FOR UC4 / UC4M / UC4MR / UC1A / UC1 / UC2A / UC2
Quantity Part No.
Description Quantity Part No. Description
4 2298A0-2 Solenoid Seat 4 236000 Seal Ring
4 210800 Seal Ring
 


292950 BALL CAGE KIT UC4 / UC4M / UC4MR / UC1A / UC1 / UC2A / UC2
Quantity Part No. Description
Quantity Part No.
Description
4 282950 Ball Cage Assembly 4 229400 Spring

29298EMV SOLENOID SEAT KIT with CHECK SEAT SEAL FOR EMV10 / EMV10T
Quantity Part No.
Description Quantity Part No. Description
2 2298EMV Solenoid Seat 2 236000 Seal Ring
2 210800 Seal Ring
2 208270
SealRing

29896EMV SOLENOID KIT FOR EMV10 / EMV10T
Quantity Part No.
Description
Quantity Part No.
Description
1 2298EMV
Solenoid Seat 1
288960 Solenoid Tube Assembly
1 236000
Seal Ring 1
238500 Seal Ring (Solenoid Tube)
1 210800
Seal Ring 1
282950 Ball Cage
1 229400
Spring 1
208270 Seal Ring
SOLENOID, SOLENOID SEAT & BALL CAGE KITS
