XPW-240 – Optional Electric
Motor Trolling Transom
Assemble the transom plate
to the transom bars as
shown using four brackets
and eight screws and nuts.
Slide the the transom bars
through both black transom
bar receivers on port and
starboard side of the stern.
Secure with two of the four
locking pins.
XPW-240 – Removable Foot Pegs
Slide the foot pegs into the foot
peg receivers on the underside of
the hull. Press the foot peg into the
rubber clasping fixture. Secure the
foot pegs with locking pins.
