Maytag MAH22PD - Washer Specifications; Maytag Energy Advantage Microprocessor Coin-Drop; Physical Dimensions and Performance; Installation and Weight

WASHER SPECIFICATIONS
MODEL MAH22PD
MOTOR
Variable-speed, reversible, thermoprotected,
high-efficiency, controlled induction
•
Wash — HP (kw) .09 (.07)
Extract — HP (kw) .54 (.40)
Average kWh per cycle .054
APPROXIMATE WATER USAGE — gallons (liters)
Average hot water usage, hot water cycle 3.4 (12.8)
Average hot water usage, warm water cycle 1.6 (6.1)
Average total water usage per cycle 13.2 (49.9)*
ELECTRICAL RATING
Domestic model — voltage 120V/60Hz
Export model — voltage 220-240V/50Hz
BREAKER/FUSE REQUIREMENTS
Domestic amps 15
Export amps 10
CYLINDER
Volume — cu. ft. (liters) 3.1 (88)
Diameter — in. (mm) 21.6 (547)
Depth — in. (mm) 13.4 (341)
DOOR OPENING
In. (mm)
14.2 (361)
WASH SPEED
RPM 40
EXTRACT SPEED
Maximum rpm 1,000
Maximum g-force 306
OPERATING PRESSURE
Psi (bar) 20-100 (1-8)
INLET HOSE
Ft. (m) 4 (1.22)
DRAIN HOSE
Ft. (m) 6 (1.83)
ADJUSTABLE LEVELING LEGS •
APPROXIMATE WEIGHT
Crated — lbs. (kg) 253 (115)
Uncrated — lbs. (kg) 244 (111)
DIMENSIONS
Width — in. (mm) 27 (685.8)
Depth — in. (mm) includes handle 29.25 (743)
Height — in. (mm) 45.67 (1160)**
* Average based on DOE J1 testing with factory preset cycles.
** Height at metercase top does not include pedestal.
Dimensions are for planning purposes only. See specific instructions for proper installation. Because of continuous
product improvement, Maytag reserves the right to change specifications without notice.
At Maytag, we believe durable goods should remain just that.
That’s why every Maytag
®
product is constructed of the
highest-quality materials and with the utmost in precision
craftsmanship. It’s also why we stand behind our equipment
with solid service and support from our professional Maytag
laundry suppliers. Simply put, when you choose Maytag
®
products, you ensure your peace of mind.
OUR COMMITMENT
TO DEPENDABLE QUALITY
11/09
MAH22PD
MAYTAG
®
COMMERCIAL
ENERGY ADVANTAGE
™
HIGH-EFFICIENCY
FRONT-LOAD
WASHER
Maytag
®
Energy Advantage
™
Front-Load Washer
MICROPROCESSOR COIN-DROP
THE BEST WARRANTY IN THE BUSINESS—
5 YEARS ON ALL PARTS
For a period from the date of original purchase through the time listed above,
the designated parts that fail in normal commercial use will be repaired or
replaced free of charge for the part itself, with the owner paying all other
costs, including labor, transportation and customs duty. Chemical damage is
excluded from all warranty coverage.
See complete warranty for details.
50.5"
(128.2 cm)
27"
(68.58 cm)
45.67"
(116 cm)
29.25"
(74.29 cm)
