7
Replace Doors and Hinges
1. Assemble the parts for the top hinge as shown in Top Hinge
graphic. Do not tighten the screws completely.
2. Replace the parts for the bottom hinge as shown in Bottom
Hinge graphic. Tighten screws. Replace the refrigerator door.
NOTE: Provide additional support for the refrigerator door
while the hinges are being moved. Do not depend on the door
gasket magnets to hold the door in place while you are
working.
3. Align the door so that the bottom of the refrigerator door
aligns evenly with the top of the freezer drawer. Tighten all
screws.
4. Reconnect the wiring plug on top of the left-hand side
refrigerator door.
5. Reconnect the water line by pulling back the locking collar
ring while firmly pushing the water line into the connector.
6. Check for leaks. Replace the top hinge covers.
Remove and Replace Refrigerator Drawer and Freezer
Drawer
IMPORTANT: Two people may be required to remove and
replace the freezer drawer. Graphics are included later in this
section.
Remove Drawer Front
1. Open the drawer to full extension.
2. Loosen the two top screws attaching the drawer glide
brackets to the drawer front. See Drawer Front Removal
graphic.
NOTE: Loosen screws three to four turns. Keep the screws in
the drawer front.
3. Remove the two bottom screws attaching the drawer glide
brackets to the drawer front.
4. Lift the drawer front up and off the top screws. See Drawer
Front Removal graphic.
Replace Drawer Front
1. Slide the drawer glides out of the compartment. Insert the
two screws in the drawer front into the upper slots in the
drawer glide brackets. See Drawer Front Replacement
graphic.
2. Align the drawer glide brackets with the lower holes in the
drawer front and refasten with the screws. See Drawer Front
Replacement graphic.
3. Completely tighten the four screws.
Final Steps
1. Replace the base grille.
2. Plug into a grounded 3 prong outlet.
3. Return all removable parts to doors and drawer and food to
refrigerator and freezer.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
