MAZ 631236 - Page 70

Схема переключения передачи Scheme of gear shifting
1, 2 – lever; 3, 4, 6 – draught; 5, 7, 17 – bolt; 8 – pin; 9 – fork; 10 – bush; 11 – spring; 12 – link;
13 – nut; 14 – tail; 15 – tip; 16 –plate; 18 – shift mechanism; 19 – ball
Figure 37 – Drive of gear-box control
