*Some models.
4
–
30
When Driving
Instrument Cluster and Display
Tachometer
*
The tachometer shows engine speed in
thousands of revolutions per minute (rpm).
CAUTION
Do not run the engine with the
tachometer needle in the RED ZONE.
This may cause severe engine damage.
Type A
*1
The range varies depending on the type
of gauge.
*1
Striped zone
*1
Red zone
Type B
*1
The range varies depending on the type
of gauge.
*1
Striped zone
*1
Red zone
NOTE
When the tachometer needle enters the
STRIPED ZONE, this indicates to the
driver that the gears should be shifted
before entering the RED ZONE.
Fuel Gauge
The fuel gauge shows approximately
how much fuel is remaining in the tank
when the ignition is switched ON. We
recommend keeping the tank over 1/4 full.
Digital speed meter type/Type A
instrument cluster/Type B instrument
cluster
Full
1/4 Full
Type C instrument cluster
Full
1/4 Full
