*Some models.
4
–
42
When Driving
Instrument Cluster and Display
Signal Indicator Lights Page
*
Rear Fog Light Indicator Light 4-66
*1 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an
expert repairer, we recommend an Authorised Mazda Repairer.
Wrench Indicator Light
When the ignition is switched ON, the
warning light is illuminated and then turns
off after a few seconds.
The wrench indicator light is illuminated
when the preset maintenance period
arrives. Verify the content and perform
maintenance.
Refer to Maintenance Monitor on page
6-15 .
SKYACTIV-D 1.5
The wrench indicator light turns on
when the engine oil has deteriorated, is
insuffi cient
*
, is around the X mark on
the oil level gauge or reaches a position
exceeding the X mark.
Check the engine oil. Refer to Inspecting
Engine Oil Level on page 6-28 .
Replace the engine oil if the wrench
indicator light does not turn off even
though the engine oil level is in the normal
range.
NOTE
Depending on the vehicle use
conditions, the range indicator light
may turn on for reasons other than
the preset maintenance period.
Whenever the engine oil is replaced,
a reset of the vehicle engine control
unit necessary.
Your Authorised Mazda Repairer will
be able to reset the engine control
unit or see page 6-27 for the Vehicle
engine control unit reset procedure.
Low Engine Coolant Temperature
Indicator Light (Blue)
The light illuminates continuously when
the engine coolant temperature is low and
turns off after the engine is warm.
If the low engine coolant temperature
indicator light remains illuminated after
the engine has been suffi ciently warmed
up, the temperature sensor could have a
malfunction. Consult an expert repairer,
we recommend an Authorised Mazda
Repairer.
