7-14
In Case of an Emergency
Flat Tire
Form No. 8Q44-EA-01K
6. With the tire facing outward, punch a
hole through the vinyl bag and the
center hole, using the flat tire securing
bolt.
7. Lift the anchor clip on the back of
third-row seat.
8. Install the flat tire with the tire securing
bolt hooked in the anchor clip as shown
below.
9. Secure the flat tire with the tire clamp
and wing nut as shown below.
Have the damaged tire repaired as soon
as possible.
Flat tire securing bolt
NOTE
•
If the tire rattles even through the
wing nut is tightened, reverse the
tire clamp and retighten the wing
nut.
•
To prevent the jack and tool from
rattling, store them properly.
Tire clamp
Wing nut
J16L_EA.book Page 14 Friday, February 22, 2002 11:34 AM
