Black plate (158,1)
The trip meter records the total distance
the vehicle is driven until the meter is
again reset. Return it to “0.0” by holding
the selector depressed for more than 1
second. Use this meter to meas ure trip
distances and to compute fuel
consumption.
NOTE
l
Only the trip meters record tenths of
kilometers (miles).
l
The trip record will be erased when
the vehicle is driven over 999.9 km
(mile).
qTachometer
The tachometer shows engine speed in
thousands of revolutions per minute
(rpm).
Red zone
CAUTION
Don't run the engine with the
tachometer needle in the RED ZONE.
This may cause severe engine damage.
qEngine Coolant Temperature
Gauge
The engine coolant temperature gauge
shows the temperature of the engine
coolant.
If the needle exceeds normal range toward
H, it indicates overheating.
CAUTION
Driving with an overheated engine can
cause serious engine da mage (page
7-16).
5-22
Driving Your Mazda
Instrument Cluster and Indicators
Mazda MPV_8T50-EA-04G_Edition1 Page158
Monday, June 28 2004 3:59 PM
Form No.8T50-EA-04G
