qSide Air Bag System Components
í
Put children in the rear seats, they do not have side air bag systems.
(2)
(1)
(3)
(4)
(1) Inflators and air bags
(2) Side crash sensor
(3) Crash sensors and diagnostic module (SAS unit)
(4) Front seats
2-62
Essential Safety Equipment
í
Some models.
SRS Air Bags
