DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
56 P/WIND L 30 A ―
57 ALARM 7.5 A ―
58 M/DEF 7.5 A Mirror Defroster
59 ―― ―
60 HEAD LOW R 15 A Headlight low beams (RH), Headlight leveling
í
61 HEAD LOW L 15 A Headlight low beams (LH)
62 ―― ―
63 ―― ―
64 ―― ―
65 SAS 10A Supplemental restraint system
66 METER 10A Instrument cluster, Immobilizer system, Shift lock system
67 IGNITION 20 A ABS
í
, EHPAS
68 WIPER 20 A Windshield wiper
69 ENGINE 20 A For protection of various circuits
70 IG SIG 10A Auto wiper
í
71 SAS 2 7.5 A Supplemental restraint system
72 ―― ―
73 ―― ―
74 SEAT WARM 20 A ―
75 D/LOCK 1 25 A Power door lock
76 A/C 10A Air conditioner, Heater control unit
77 P/WIND L 30 A Power window (LH)
í
78 P/WIND R 30 A Power window (RH)
í
79 BACK 10A Reverse lights
80 SUN ROOF 7.5 A Moonroof
í
81 TAIL L 7.5 A Taillights (LH), Parking lights (LH)
82 ILLUMI 7.5 A Illumination
83 ―― ―
84 ―― ―
85 ―― ―
86 ―― ―
8-58
Maintenance and Care
í
Some models.
