qReplacing Interior Light Bulbs
Overhead light/Map lights (Front)
1. Remove the screws.
2. Wrap a flathead screwdriver with a soft
cloth to prevent damage to the trim and
gently insert it in the overhead light as
shown in the figure, and then remove
the overhead light unit.
3. Turn the socket and bulb assembly
counterclockwise and remove it.
4. Disconne ct the bulb from the socket.
5. Install the new bulb in the reverse order
of removal.
Overhead light/Map lights (Rear)
1. Wrap a flathead screwdriver with a soft
cloth to prevent damage to the trim and
gently insert it in the overhead light as
shown in the figure, and then remove
the overhead light unit.
2. Turn the socket and bulb assembly
counterclockwise and remove it.
3. Disconne ct the bulb from the socket.
4. Install the new bulb in the reverse order
of removal.
