Black plate (191,1)
0―Fan off
1―Low speed
2―Medium speed
3―High speed
NOTE
When the rear air conditioner main
switch is not set to the REAR position,
the fan control dial of the rear air
conditioner control panel does not
work.
The front air conditioner controls
override the rear controls.
Mode selector dial (Type B)
Turn the dial to select the cooler mode or
the heater mode.
―cooler mode
―heater mode
Interior Comfort
Climate Control System
6-13
Mazda MPV_8U61-EA-05G_Edition1 Page191
Tuesday, June 21 2005 9:35 AM
Form No.8U61-EA-05G
