Black plate (30,1)
WARNING
Lifting the Seat-Anchor Bar:
Lifting the seat- anchor bar without
firmly supporting the seat with your
hand is dangerous. Lifting the seat
unlocks the front clamps
automatically and could cause the seat
to fall. Support the seat firmly while
lifting the seat-anchor bar.
To remove the seat
1. Put the buckle in the pocket of the seat
bottom.
CAUTION
Lowering the seatback without stowing
the seat belt buckle could damage the
seatback.
2. Remove the head restraint.
3. Slide the seat all the way back.
4. Raise the reclining lever and lower the
seatback forward.
Make sure the seatback is locked .
5. Work only on one seat at a time to
avoid one seat falling while working on
another.
6. Lift and hold the seat-anchor bar and
raise the entire seat up and forward.
2-18
Essential Safety Equipment
Seats
Mazda MPV_8U61-EA-05G_Edition1 Page30
Tuesday, June 21 2005 9:32 AM
Form No.8U61-EA-05G
