Examples: Based on a single occupant weight of 68 kg, and a value of 385 kg for the
“combined weight of occupants and cargo should never exceed”:
The cargo weight limit with one occupant is 385 kg
_
68 kg = 317 kg
The cargo weight limit with two occupants is 385 kg
_
(68 × 2) kg = 249 kg
If the weight of the occupant increases, the cargo weight limit decreases by that much.
GAW (Gross Axle Weight) is the total weight placed on each axle (front and rear) -
including vehicle curb weight and all payload.
GAWR (Gross Axle Weight Rating) is the maximum allowable weight that can be carried
by a single axle (front or rear). These numbers are shown on the Safety Compliance
Certification Label located on the driver's door or door pillar. The total load on each
axle must never exceed its GAWR.
GVW
GVW (Gross Vehicle Weight) is the Vehicle Curb Weight + cargo + passengers.
GVWR (Gross Vehicle Weight Rating) is the maximum allowable weight of the fully
loaded vehicle (including all options, equipment, passengers and cargo). The GVWR is
shown on the Safety Compliance Certification Label located on the driver's door or
door pillar. The GVW must ne ver exceed the GVWR.
9-32
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
Mazda MPV_8U61-EA-05G_Edition1 Page342
Tuesday, June 21 2005 9:38 AM
Form No.8U61-EA-05G
