ON-BOARD DIAGNOSTIC
04–02–8
End Of Sie
ON-BOARD DIAGNOSTIC SYSTEM ACTIVE COMMAND MODES FUNCTION (ABS, DYNAMIC STABILITY
CONTROL)
E5U040243750N04
• The active command modes function is used for optionally selecting active command modes items of input/
output parts preset in the ABS HU/CM or DSC HU/CM, and to operate them regardless of CM control.
• To protect the hydraulic unit interior, operate output related parts for only 10 s or less when using the active
command modes function.
Active Command Modes Table (Vehicles with ABS)
Active Command Modes Table (Vehicles with DSC)
End Of Sie
Command name Output part name Operation
Operation
condition
LF_INLET LF inlet solenoid valve
On/Off
Ignition switch at
ON
LF_OUTLET LF outlet solenoid valve
LR_INLET LR inlet solenoid valve
LR_OUTLET LR outlet solenoid valve
PMP_MOTOR Pump motor
RF_INLET RF inlet solenoid valve
RF_OUTLET RF outlet solenoid valve
RR_INLET RR inlet solenoid valve
RR_OUTLET RR outlet solenoid valve
Command name Output part name Operation
Operation
condition
LATACCEL Combined sensor (lateral acceleration) initialization FALSE/TRUE
Ignition switch at
ON
LF_INLET LF inlet solenoid valve
On/Off
LF_OUTLET LF outlet solenoid valve
LR_INLET LR inlet solenoid valve
LR_OUTLET LR outlet solenoid valve
PMP_MOTOR Pump motor
RF_INLET RF inlet solenoid valve
RF_OUTLET RF outlet solenoid valve
RR_INLET RR inlet solenoid valve
RR_OUTLET RR outlet solenoid valve
SAS_CAL Steering angle sensor initialization FALSE/TRUE
STAB_IND DSC indicator light
On/Off
TRAC_OFF DSC OFF switch
V_STB_L LF stability control solenoid valve
V_STB_R RF stability control solenoid valve
V_TRC_L LF traction control solenoid valve
V_TRC_R RF traction control solenoid valve
YAWRATE Combined sensor (yaw rate) initialization
