Luggage compartment cover
í
Installing the cover
1. Insert the left end of the retractor bar
into the notch.
2. Squeeze the spring holder on right end
of the retractor bar inward, then insert
it into the notch.
3. Slowly pull out the cover and insert it
into the retainers.
Hook
retainer
Removing the cover
Reverse the procedure for installation.
3-34
Knowing Your Mazda
í
Some models.
Doors and Locks
