DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
17 OUTLET CTR 15 A Accessory socket (Center)
18 OUTLET RR 15 A Accessory socket (Rear)
19 AC PWR 15 A Moon roof
í
, DC/AC inverter
20 S.WARM 15 A Seat warmer
í
21 A/C MAG 10 A Air conditioner
22 BOSE 25 A Audio system (Bose
®
Sound System-equipped model)
í
23 FAN2
30 A
í
Cooling fan
40 A
í
24 ABS 50 A ABS
25 IG COIL 25 A Ignition system
26 H/L LOW L 15 A Headlight-left (Low beam)
27 H/L LOW R 15 A Headlight-right (Low beam)
28 H/L HIGH 20 A Headlight-high (High beam)
29 HAZARD 15 A Hazard warning flashers
30
10 A PCM
31 HORN 15 A Horn
32 STOP 7.5 A Brake lights
33 EGI INJ 10 A Engine control system
34 ENG BAR 20 A Air flow sensor, EGR control valve
35 ENG BAR 2 7.5 A PCM
Maintenance and Care
Owner Maintenance
8-49
í
Some models.
