Black plate (220,1)
Temperat ure control dial
This dial controls temperature. Turn it
clockwise for hot and counterclockwise
for cold.
l
When the DUAL switch is off:
Turn the driver temperature control dial
to control the temperature throughout
the entire cabin.
l
When the DUAL switch is on:
Turn the driver or front passenger
temperature control dial to
independently control the temperature
on each side of the cabin.
NOTE
The system changes to the individual operation
mode (DUAL switch indicator light
illuminated) by turning the front passenger
temperature control dial even when the DUAL
switch is off, which allows individual control
of the set temperature for the driver and front
passenger.
Fan control dial
The fan has seven speeds. The selected
speed will be displayed.
Mode selec tor switch
The desired airflow mode can be selected
(page 5-4).
NOTE
l
With the airflow mode set to the
position and the temperature control dial
set at a medium temperature, heated air is
directed to the feet and air at a comparably
lower temperature will flow through the
central, left and right vents.
l
To set the air vent to , press the
windshield defroster switch.
l
In the or position, the air
conditioner is automatically turned on and
the outside air mode is automatically
selected to defrost the windshield. In the
or position, the outside air mode
cannot be changed to the recirculated air
mode.
A/C switch
Pressing the A/C switch while the AUTO
switch is turned on will turn off the air
conditioning (cooling/dehumidifying
functions).
The air conditioning can be turned on and
off by pressing the A/C switch while the
fan control dial is on.
NOTE
l
The air conditioning operates when the A/C
switch is pressed even if the fan is off.
l
The air conditioner may not function when
the outside temperature approaches 0 °C
(32 °F). (Indicator light remains on even
when system is off.)
Air intake selector
Outside or recirculated air positions can
be selected. Press the switch to select
outside/recirculated air positions.
Recirculated air position (
)
Use this position when going through
tunnels, driving in congested traffic (high
engine exhaust areas) or when quick
cooling is desired.
