qComponent Parts
Microphone
Talk button, Pick-up button and Hang-up button
Microphone
Talk button
Hang-up button
Pick-up button
Audio unit
Audio unit (Type B)
The audio unit (Type B) is used for volume adjustment and touch panel operation.
Bluetooth
®
information is displayed in the display. The screen is switched by touchi ng the
tab for each function to be used.
CAUTION
Do not press the panel strongly or press it with a sharp-pointed object.
Display OFF
The audio unit d isplay can be switched off by voice recognition operation.
1. Press the pick-up button or talk button.
2. Say: [Beep] “Display OFF”
Numeral or symbol entry
Use the numerical keypad.
Long-press the
on-screen button to input .
Touch the
on-screen button to delete the currently input value.
5-78
Interior Features
Bluetooth®
