Black plate (345,1)
2. Firmly rotate the wiper blade to the
right unti l it unlocks, then remove the
blade.
CAUTION
To prevent damage to the rear
window, do not let the wiper arm fall
on it.
3. Pull down the blade rubber and slide it
out of the blade holder.
4. Remove the metal stiffeners from the
blade rubber and install them in the
new blade.
CAUTION
Do not bend or discard the stiffeners.
You need to use them again.
5. Careful ly insert the new blade rubber.
Then install the blade assem bly in the
reverse order of removal.
Maintenance and Care
Owner Maintenance
6-29
