When Driving
Instrument Cluster and Display
M e t e r s a n d G a u g e s
Type A
Type B
Type C
Steering Switch
(Digital Speed Meter Type)
(Analog Speed Meter Type (With Tachometer))
(Analog Speed Meter Type (Without Tachometer))
Some models.
Instrument Cluster

Speedometer .......................................................................................................... page 4-24

Odometer, Trip Meter and Trip Meter Selector .................................................... page 4-24

Tachometer ............................................................................................................ page 4-26

Fuel Gauge ............................................................................................................ page 4-26

Instrument Panel Illumination ............................................................................... page 4-27

Outside Temperature Display ................................................................................ page 4-28

Cruise Control Set Vehicle Speed Display ............................................................ page 4-29

Multi Information Display .................................................................................... page 4-32

Active Driving Display ......................................................................................... page 4-38
