Mazda 3 - Page 377

4 – 233
When Driving
Parking Sensor System
*Some models.
Viewing distance display
Display Distance between vehicle and obstruction
Without front sensor
and front corner sensor
With front sensor and
front corner sensor
Front Sensor
*
/Front
Corner Sensor
*
Rear Sensor/Rear Corner
Sensor
Front sensor:
Approx. 100—60 cm
(39.3—23.6 in)
Rear sensor:
Approx. 150—60 cm
(59.0—23.6 in)
Front sensor:
Approx. 60—45 cm
(23.6—17.7 in)
Front corner sensor:
Approx. 50—37 cm
(19.6—14.6 in)
Rear sensor:
Approx. 60—45 cm
(23.6—17.7 in)
Rear corner sensor:
Approx. 50—37 cm
(19.6—14.6 in)
Front sensor:
Approx. 45—35 cm
(17.7—13.7 in)
Front corner sensor:
Approx. 37—25 cm
(14.6—9.8 in)
Rear sensor:
Approx. 45—35 cm
(17.7—13.7 in)
Rear corner sensor:
Approx. 37—25 cm
(14.6—9.8 in)
