4. Pull the strap and lift the end of the
seat-bottom up and forward.
5. If the armrest and storage box are in
the position for use, store them.
Refer to Storage Box on page 6-105.
6. Raise the lever and fold the seatback
forward. Make sure the seatb ack is
secured by attempting to lightly move
it up and down.
CAUTION
Ø When folding a seatback, always
hold onto the seatback with your
other hand while operating the
lever. If the seatback is not
supported, it will flip forward
suddenly and could cause injury.
Ø When folding the seatback of the
right second-row seat, make sure
the storage box is stowed. If the
storage box is not stowed, it could
be damaged.
NOTE
To create a flat luggage compartment space
from the rear of the vehicle to the back of the
front seats, fold the second-row and third-row
seats (page 2-11).
Essential Safety Equipment
Seats
2-9
