NOTE
l
To replace the bulb, contact an Authorized
Mazda Dealer
l
If the halogen bulb is accidentally touched,
it should be cleaned with rubbing alcohol
before being used.
l
Use the protective cover and carton of the
replacement bulb to dispose of the old bulb
promptly out of the reach of children.
Front turn signal lights/Front side-
marker lights/Parking lights
1. Make sure the ignition is switched off,
and the headlight switch is off.
2. Lift the hood.
3. Turn the socket and bulb assembly
counterclockwise and remove it.
4. Remove the bulb by pressing it in
slightly and turning it
counterclockwise.
5. Install the new bulb in the reverse order
of the removal procedure.
Side turn signal lights
í
The LED bulb cannot be replaced as a
single unit because it is an integrated unit.
The LED bulb has to be replaced with the
unit. We recommend an Authorized
Mazda Dealer when the replacement is
necessary.
Brake lights/Taillights/Rear side-
marker lights, Rear turn signal lights
1. Make sure the ignition is switched off,
and the headlight switch is off.
2. Turn the bolts counterclockwise and
remove them.
3. Pull the upper part of the cover around
the clip outward to detach the clip.
Clip
8-38
Maintenance and Care
í
Some models.
Owner Maintenance
