DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
13
FAN1 30 A Cooling fan
AT PUMP ――
14 P.SLIDE R ――
15 EHPAS 80 A Power assist steering
16 FOG 15 A Fog lights
í
17 D.LOCK 20 A Power door lock
18 P.WIND 20 A Power window
19
AT PUMP ――
TCM ――
20 HEAD HI 20 A Headlight high beam
21
10 A Engine control system
22 STOP 10 A Brake lights
23
F.WARMER
FUEL PUMP
20 A Fuel system
24 HAZARD 10 A Hazard warning flasher, Turn signal lights
25 ROOM 15 A Overhead lights
26
TAIL
ENG FAN
15 A Taillights, Parking lights, License plate lights
27 A/C MAG 10 A Air conditioner
28
ABS V 20 A ABS, Dynamic stability control system
HORN ――
29
SUN ROOF 20 A Moonroof
í
AUDIO1 ――
30
H/CLEAN ――
DCDC3 ――
31
HORN 15 A Horn
ABS V ――
32 TAIL ――
33 ILLUMI 7.5 A Instrument panel illumination
34 ENG INJ 25 A Engine control system
35 ENG BAR 15 A Engine control system
36 ―― ―
37 M.DEF 7.5 A Mirror defogger
38 DEFOG 25 A Rear window defogger
39 HEAD LO L 15 A Headlight low beam (LH)
40 HEAD LO R 15 A Headlight low beam (RH)
8-46
Maintenance and Care
í
Some models.
