Check the tire pressure label for tire size and inflation pressure.
Refer to Tire Inflation Pressure on page 8-28.
Standard tire
Tire size
Inflation pressure
Front Rear
P205/55R16 89H 240 kPa (35 psi) 240 kPa (35 psi)
205/50R17 89V 230 kPa (34 psi) 230 kPa (34 psi)
Temporary tire
Tire size Inflation pressure
T125/70D16 96M 420 kPa (60 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
88―118 N·m (9―12 kgf·m, 65―87 ft·lbf)
qFuses
Refer to Fuses on page 8-42.
Specifications
10-7
