In
Case of Emergency
6-13
NUMBER
FUSE
RATING
PROTECTED
COMPONENT
11 7.5A
Instrument
C
luster
, M
ai
n L
igh
t S
witch
, R
ABS
Resistor
12 — —
13 20A
Brake Pedal Position Switch
14 20A
RABS Module
14 10A 4W
ABS Mod., 4W
ABS Main Relay
15 —
Not Used
16 30A
W/W Motor
, W
iper Hi-Lo Relay
, W
iper Run/Park
Relay
, W
asher Pump Relay
17 25A
Cigar Lighter
, Data Link Connector (DLC)
18 —
Not Used
19 25A
PCM Power Diode, Ignition, P
AT S
20 7.5A
GEM/CTM, Radio
NUMBER
FUSE
RATING
PROTECTED
COMPONENT
21 20A Flasher
22 20A Auxiliary
Power Point
23 — —
24 7.5A
Clutch Pedal Position (CPP) Switch, Starter
Interrupt Relay
25 — Not Used
26 10A
Battery Saver Relay
, 4x4 Electronic Shift Relay
,
Interior Lamp Relay, 4x4 Elec. Shift Control
Module, D
ome/Ma
p L
amp, Instrument
Illumination Dimmin
g M
odule
, R
estrain
t C
ontrol
Module, GEM/CTM, Instrumen
t C
luster
27 — Not Used
28 7.5A
GEM/CTM System, Radio
29 15A Radio
30 — Not Used
