Mazda BT-50 2014 - INSTRUMENTS, WARNING LIGHTS AND INDICATOR LIGHTS

4-13
CONTROLS AND INSTRUMENTS
INSTRUMENTS, WARNING LIGHTS AND
INDICATOR LIGHTS
●
How to Read the Instruments (Instruments Layout) 4-14
●
Tachometer 4-16
●
Speedometer 4-16
●
Odometer and Trip Meter 4-17
●
Engine Coolant Temperature Gauge 4-18
●
Fuel Gauge 4-19
●
Warning and Indicator Lights Layout 4-21
●
Illumination of Center Display 4-26
●
Multi-Information Display (MID) 4-27
●
Liquid Crystal Display (LCD) 4-48
●
Head Up Display 4-58
●
Warning and Indicator Lights 4-59
●
Warning Buzzer 4-107
