3. Turn the screw counterclockwise and
remove it.
4. Pull the center of each plastic retainer
and remove the retainers, and then
partially peel back the mudguard.
Removal
Installation
5. Disconnect the wiring harness by
releasing the clamp.
6. Turn the socket and bulb assembly
counterclockwise and remove it.
7. Disconnect the bulb from the socket.
Front turn signal lights
Maintenance and Care
Owner Maintenance
6-40
