Temporary spare tire
(U.S.A. and Canada)
Tire size Inflation pressure
T155/90D17 101M 420 kPa (60 psi)
(Mexico)
Tire size Inflation pressure
185/80R17 99M 320 kPa (3.2 bar, 46 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108―147 N·m (12―14 kgf·m, 80―108 ft·lbf)
▼
Fuses
Refer to Fuses on page 6-46.
Specifications
Specifications
9-8
