Meters and Gauges
(Black-out meter)
When the ignition is switched ON, the dashboard gauges illuminate.
Speedometer ...................................................................................................... page 5-36
Odometer, Trip Meter and Trip Meter Selector .................................................. page 5-36
Tachometer ........................................................................................................ page 5-37
Fuel Gauge ........................................................................................................ page 5-37
Boost Gauge (2.3-liter engine) .......................................................................... page 5-38
Dashboard Illumination ......................................... ............................................ page 5-39
