Black plate (349,1)
qJack
To remove the jack
(4 Door)
1. Remove the cover.
2. Turn the wing bolt and jack screw
counterclockwise.
Wing bolt
Jack screw
(5 Door)
1. Turn the knob and remove the cover.
2. Turn the wing bolt and jack screw
counterclockwise.
Wing bolt
Jack screw
In Case of an Emergency
Flat Tire
7-5
Mazda3_8AR2-EC-09E_Edition1 Page349
Thursday, April 9 2009 4:10 PM
Form No.8AR2-EC-09E
