Black plate (413,1)
3. Turn the socket and bulb assembly to
remove it. Carefully remove the bulb
from its socket in the reflector by
gently pu lling it straight backward out
of the socket.
4. Install the new bulb in the reverse order
of the removal procedure.
Parking lights/Front turn signal lights/
Front side-marker lights
1. Make sure the ignition is switched off
and the headlight switch is off.
2. If you are changing the right bulb, start
the engine, turn the steering wheel all
the way to the left, and turn off engine.
If you are changing the left bulb, turn
the steering wheel to the right.
3. Turn the cen ter section of the plastic
retainer counterclockwise and remove
the retainers and partially peel back the
mudguard.
Installation
Removal
4. Turn the socket and bulb assembly
counterclockwise and remove it.
5. Disconnect the bulb from the socket.
Maintenance and Care
Owner Maintenance
8-43
Mazda3_8AR2-EC-09E_Edition1 Page413
Thursday, April 9 2009 4:11 PM
Form No.8AR2-EC-09E
