5. Pull off the sealing cover.
6. Unhook the bulb retaining spring.
7. Swing the retaining spring out and
away to free the headlight bulb.
8. Carefully remove the socket and bulb
assembly by pulling it straight back.
9. Remove the headlight bulb from the
socket.
10. Install the new socket and bulb
assembly in the reverse order of
removal.
NOTE
l
If the halogen bulb is accidentally
touched, it should be cleaned with
rubbing alcohol before being used.
l
Use the protective cover and carton
for the replacement bulb to dispose
of the old bulb promptly and out of
the reach of c hildren.
l
When reinstalling the sealing cover,
make sure
faces up.
Front fog light bulbs
í
1. If you are changing the right Front fog
light bulb, start the engine, turn the
steering wheel all the way to the left,
and turn off the engine. If you are
changing the left Front fog light bulb,
turn the steering wheel to the right.
2. Turn the screws counterclockwise and
remove them.
Maintenance and Care
Owner Maintenance
8-41
í
Some models.
