If Trouble Arises
When Trunk Lid Cannot be Opened
12. Remove the windblocker.
Windblocker
13. Partially peel back the cover on the
right side from the middle of the
vehicle.
14. Pull out the cap and release the trunk
lock.
After performing this emergency
measure, have the vehicle inspected at
an Authorized Mazda Dealer as soon as
possible.
CAUTION
Do not pull the screw when pulling the
cap. Otherwise, the screw may fall o
and become lost.
Roof does not operate electrically
1. Remove the antenna if it is
installed.Refer to Antenna on page
5-13.
2. Lift up the rear roof by hand.
Refer to When the Roof Cannot be
Closed on page 7-57.
3. Remove the fasteners on the right side
of the vehicle.
4. Push the stopper rubber through the
cover on the right side of the vehicle
while slightly lifting the cover up.
Cover
Stopper Rubber
MX-5_8FR4-EA-16J_Edition1.indb 55 2016/08/11 20:30:08
To Next Page
