Mazda RX8 - Page 11

1 Screw A
2 Airdam skirt
3 Bolt A
4 License plate holder
5 Fastener
6 Front bumper mesh
7 Bolt B
8 Set plate
9 Front bumper retainer No.1
10 Screw B
11 Screw C
12 Front fog light hole cover
13 Front bumper fascia
3. Assemble in the reverse order of disassembly.
(w) RX-8 Body
Page 11
